How to Program:

DSC recommends filling in the Programming Worksheet with the required
programming information before programming the system. This will reduce the
time required to program and will help eliminate errors.

To enter Installer Programming press [*][8][5555].
The Program light will FLASH (or in the case of the programmable LCD keypad
the display will change to ‘Enter Section’).

An error tone indicates the installer code entered is not correct.
Press [#] to clear any key presses and try again

.

The Armed and Ready lights indicate programming status:

Armed Light ON

Panel waiting for 3-digit section number

Ready Light ON

Panel waiting for data to be entered

Ready Light FLASHING

Panel waiting for HEX data to be entered

NOTE:

You cannot enter installer programming while the system is armed or
in alarm.

Programming Toggle Options:

Enter the 3-digit programming section number.
•

The Armed light will turn OFF and

•

The Ready light will turn ON.

•

The keypad will display which toggle options are ON or OFF according to
the chart below:

•

To toggle an option ON or OFF, press the corresponding number on the
keypad. The display will change accordingly.

•

When all the toggle options are configured correctly, press the [#] key to
exit the program section.

•

The Ready light will turn OFF and the Armed light will turn ON.

NOTE:

If the panel is a local system, press [#] to skip this step.

NOTE:

In addition to the standard digits 0-9, HEX digits can also be
programmed if required.

Programming Decimal and Hexadecimal (HEX) Data:

•

Enter the 3-digit programming section number.

Manual

•

The Armed light will turn OFF and The Ready light will turn ON.

•

Enter the data written in the boxes.

For sections that require multiple 2 or 3 digit numbers, the keypad will
double-beep after each 2 or 3 digit entry and move to the next item in
the list. After the last digit in the section is entered, the keypad will
beep rapidly 5 times and exit the program section. The Ready light will
turn OFF and the Armed light will turn ON.

For sections that do not require data for every box (such as phone
numbers) press the [#] key to exit the program section after entering all

the required data. The Ready light will turn OFF and the Armed light
will turn ON.
At any time the [#] can be pressed to exit any program section. All
changes made up to that point will be saved.

HEX (or hexadecimal) digits are sometimes required. To enter a HEX
digit, press the [*] key to begin HEX programming. The Ready light will
FLASH. Refer to the chart below and press the number corresponding
to the HEX digit required. The Ready light will continue to FLASH.
Press [*] again to return to normal decimal programming. The Ready
light will turn ON.

HEX [A]

[*] [1] [*]

HEX [B]

[*] [2] [*]

HEX [C]

[*] [3] [*]

HEX [D]

[*] [4] [*]

HEX [E]

[*] [5] [*]

HEX [F]

[*] [6] [*]

Manual

How to Exit Installer Programming:

1864

To exit installer programming, press the [#] key when the panel is
waiting for a 3-digit section number (the Armed light is ON).

Viewing Programming

LED and LCD5501Z Keypads

Any programming section can be viewed from an LED or LCD5501Z key-
pad. When a programming section is entered, the keypad will immediately
display the first digit of information programmed in that section.
The keypad displays the information using a binary format, according to
the following chart:

See Hex data

entry instructions

Press any of the Emergency keys (Fire, Auxiliary or Panic) to advance to
the next digit.
When all the digits in a section have been viewed, the panel will exit the
section: the Ready light will turn OFF, and the Armed light will turn ON,
waiting for the next 3-digit programming section number to be entered.
Press the [#] key to exit the section

LCD Keypad

When a programming section is entered, the keypad will immediately dis-
play all the information programmed in that section. Use the arrow keys (<
>) to scroll through the data being displayed. To exit the section, scroll
past the end of the data displayed, or press the [#] key.

DLS Programming

Hardware Setup - Local (PC-Link)

Connect a RS-232 to PC-Link Cable between the Computer with DLS
Software installed and the alarm panel to be programmed.

[401] First Downloading Option Code

The 1

st

toggle option in this section is used to enabled/disable Downloading.

Configure the options as required and press [#] to exit

.

PROGRAMMING

Keypad Type

Option ON

Option OFF

LED

Zone Light ON

Zone Light OFF

Fixed-Message LCD

Indicator # ON

Indicator # OFF

Programmable-Message LCD

# Displayed

Dash [-] Displayed

HEX [A]
HEX [B]
HEX [C]
HEX [D]
HEX [E]

Not Supported
Simulated [*] key
Simulated [#] key
Dial tone search
Two second pause

Press [*][2][*]
Press [*][3][*]
Press [*][4][*]
Press [*][5][*]

Opt

Default

Description

Dsc 1864 Programming Manual 2017

2

I__I

✔

ON

User can enable DLS Window

OFF

Dsc 1864 Installation Manual Download

User can NOT enable DLS Window
